Product Details

SLIDE PLATE (PCU-CA37)-B

Material : Copper alloy Special Solid lubricant (embedded)

Width (W) : 50 & 75 mm

Length (L) : 150-250 mm

Order Type : PCU-CA37-W-L-T

Example : PCU-CA3-50-200-20

Product of: Pawan

Add to cart	CAD File	Item Code	W (mm)	L (mm)	T (mm)	L (mm)	L1 (mm)	H (mm)
		PCU-CA37-50-150-20	50	150	20	50	-	8	11	17.5
		PCU-CA37-50-200-20	50	200	20	75	-	8	11	17.5
		PCU-CA37-50-250-20	50	250	20	75	50	8	11	17.5
		PCU-CA37-50-150-35	50	150	35	50	-	20	13	20
		PCU-CA37-50-200-35	50	200	35	75	-	20	13	20
		PCU-CA37-50-250-35	50	250	35	75	50	20	13	20
		PCU-CA37-75-150-20	75	150	20	50	-	8	11	17.5
		PCU-CA37-75-200-20	75	200	20	75	-	8	11	17.5
		PCU-CA37-75-250-20	75	250	20	75	50	8	11	17.5
		PCU-CA37-75-150-35	75	150	35	50	-	20	13	20
		PCU-CA37-75-200-35	75	200	35	75	-	20	13	20
		PCU-CA37-75-250-35	75	250	35	75	50	20	13	20
