Product Details

Material : 1. Copper alloy Special Solid lubricant (embedded)-For Type-B

2. EN8 -For Type-S

Hardness : 55 HRC (Induction Hardened)

Width (W) : 60 & 80 mm

Length (L) : 85 mm

Order Type : PCU-CA29-W-L-Type

Example : PCU-CA29-60-85-B (Type-B)

PCU-CA29-60-85-S (Type-S)

Item Code	Type	W (mm)	L (mm)	L1 (mm)
PCU-CA29-60-85-B	Type-B	60	30	15
PCU-CA29-80-85-B	Type-B	80	40	20
PCU-CA29-60-85-S	Type-S	60	30	15
PCU-CA29-80-85-S	Type-S	80	40	20
