Product Details

Material : 1.EN8 - For Type -S

2.Copper alloy Special solid lubricant(embedded) - For Type-B

Hardness: 55 HRC(induction Hardened) - Type -S

Width (W) : 150 & 200 mm

Length (L) : 170, 200 mm

Order Type : PCU-CA8-W-L-Type

Example : PCU-CA8-150-170-S (For S-Type)

PCU-CA8-150-170-B(For B-Type)

Item Code	Type	W (mm)	L (mm)	A (mm)	t (mm)
PCU-CA8-150-170-B	Type-B	150	170	100	60
PCU-CA8-150-200-B	Type-B	150	200	100	90
PCU-CA8-200-170-B	Type-B	200	170	140	60
PCU-CA8-200-200-B	Type-B	200	200	140	90
PCU-CA8-150-170-S	Type-S	150	170	100	60
PCU-CA8-150-200-S	Type-S	150	200	100	90
PCU-CA8-200-170-S	Type-S	200	170	140	60
PCU-CA8-200-200-S	Type-S	200	200	140	90
