Product Details

Material : 1.EN8 - For Type -S

2.Copper alloy Special solid lubricant(embedded) - For Type-B

Hardness: 55 HRC(induction Hardened) - Type -S

Width (W) : 50,75,100 mm

Length (L) : 110 to 130 mm

Order Type : PCU-CA6-W-L-Type

Example : PCU-CA6-75-130-S (For S-Type)

PCU-CA6-75-130-B(For B-Type)

Item Code	Type	W (mm)	L (mm)	A (mm)	t (mm)
PCU-CA6-50-110-B	Type-B	50	110	-	25
PCU-CA6-50-130-B	Type-B	50	130	-	30
PCU-CA6-50-150-B	Type-B	50	150	-	35
PCU-CA6-75-110-B	Type-B	75	110	40	25
PCU-CA6-75-130-B	Type-B	75	130	40	30
PCU-CA6-75-150-B	Type-B	75	150	40	35
PCU-CA6-100-110-B	Type-B	100	110	60	25
PCU-CA6-100-130-B	Type-B	100	130	60	30
PCU-CA6-100-150-B	Type-B	100	150	60	35
PCU-CA6-50-110-S	Type-S	50	110	-	25
PCU-CA6-50-130-S	Type-S	50	130	-	30
PCU-CA6-50-150-S	Type-S	50	150	-	35
PCU-CA6-75-110-S	Type-S	75	110	40	25
PCU-CA6-75-130-S	Type-S	75	130	40	30
PCU-CA6-75-150-S	Type-S	75	150	40	35
PCU-CA6-100-110-S	Type-S	100	110	60	25
PCU-CA6-100-130-S	Type-S	100	130	60	30
PCU-CA6-100-150-S	Type-S	100	150	60	35
