Spring Plunger (Pin Type) - PSP-P

Technical Description

Material :- En8d
Hardness :- 32-38 HRC
Surface Treatment :- Blackodised

Coarse Thread (K) Range :- 3mm to 30mm
Flange (F) Range :- 1.5mm to 40mm

Order Type :- Code X K X F
Example :- PSP-P X 6 X 10
Availability – Ready
(*Note - This is tentative schedule, may vary as per material availability)

Item Details


Item code	CAD	K in mm	F in mm	d (mm)	L (mm)	A (mm)	l (mm)
PSP-P - 3x1.5		3	1.5	1.1	10	0.9	10
PSP-P - 3x3		3	3	1.1	15	0.9	15
PSP-P - 4x2		4	2	1.6	15	1.3	15
PSP-P - 4x4		4	4	1.6	24	1.3	24
PSP-P - 5x3		5	3	2	20	1.5	20
PSP-P - 5x5		5	5	2	27	1.5	27
PSP-P - 6x3		6	3	2.5	25	2	25
PSP-P - 6x5		6	5	2.5	30	2	30
PSP-P - 6x10		6	10	2.5	39	2	30
PSP-P - 8x3		8	3	3.1	25	2.5	25
PSP-P - 8x5		8	5	3.1	27	2.5	27
PSP-P - 8x10		8	10	3.1	43	2.5	30
PSP-P - 10x5		10	5	3.8	30	3	30
PSP-P - 10x10		10	10	3.8	43	3	30
PSP-P - 10x15		10	15	3.8	58	3	30
PSP-P - 12x5		12	5	5.5	30	4	30
PSP-P - 12x10		12	10	5.5	43	4	35
PSP-P - 12x15		12	15	5.5	51	4	35
PSP-P - 12x20		12	20	5.5	78	4	35
PSP-P - 16x10		16	10	8	60	5	35
PSP-P - 16x15		16	15	8	60	5	35
PSP-P - 16x20		16	20	8	85	5	35
PSP-P - 16x30		16	30	8	125	5	35
PSP-P - 16x40		16	40	8	125	5	35
PSP-P - 16x50		16	50	8	155	5	35
PSP-P - 16x60		16	60	8	159	5	35
PSP-P - 16x70		16	70	8	185	5	35
PSP-P - 16x80		16	80	8	185	5	35
PSP-P - 20x15		20	15	10	60	6	45
PSP-P - 20x20		20	20	10	72	6	45
PSP-P - 20x30		20	30	10	96	6	45
PSP-P - 20x40		20	40	10	120	6	45
PSP-P - 24x7		24	7	10	60	10	45
PSP-P - 24x15		24	15	10	60	10	45
PSP-P - 24x20		24	20	10	75	10	45
PSP-P - 24x30		24	30	10	100	10	45
PSP-P - 24x40		24	40	10	124	10	45
PSP-P - 30x15		30	15	14	66	14	45
PSP-P - 30x20		30	20	14	78	14	45
PSP-P - 30x30		30	30	14	100	14	45
PSP-P - 30x40		30	40	14	123	14	45
PSP-PT- 3x1.5		3	1.5	1.1	15	0.9	15
PSP-PT- 3x3		3	3	1.1	20	0.9	20
PSP-PT- 4x2		4	2	1.6	24	1.3	24
PSP-PT- 4x4		4	4	1.6	24	1.3	24
PSP-PT- 5x3		5	3	2	27	1.5	27
PSP-PT- 5x5		5	5	2	39	1.5	39
PSP-PT- 6x3		6	3	2.5	30	2	30
PSP-PT- 6x5		6	5	2.5	36	2	36
PSP-PT- 6x10		6	10	2.5	-	2	30
PSP-PT- 8x3		8	3	3.1	27	2.5	27
PSP-PT- 8x5		8	5	3.1	35	2.5	30
PSP-PT- 8x10		8	10	3.1	-	2.5	30
PSP-PT- 10x5		10	5	3.8	35	3	30
PSP-PT- 10x10		10	10	3.8	53	3	30
PSP-PT- 10x15		10	15	3.8	-	3	30
PSP-PT- 12x5		12	5	5.5	43	4	35
PSP-PT- 12x10		12	10	5.5	58	4	35
PSP-PT- 12x15		12	15	5.5	78	4	35
PSP-PT- 12x20		12	20	5.5	-	4	35
PSP-PT- 16x10		16	10	8	60	5	35
PSP-PT- 16x15		16	15	8	70	5	35
PSP-PT- 16x20		16	20	8	90	5	35
PSP-PT- 16x30		16	30	8	125	5	35
PSP-PT- 16x40		16	40	8	-	5	35
PSP-PT- 16x50		16	50	8	-	5	35
PSP-PT- 16x60		16	60	8	-	5	35
PSP-PT- 16x70		16	70	8	-	5	35
PSP-PT- 16x80		16	80	8	-	5	35
PSP-PT- 20x15		20	15	10	80	6	45
PSP-PT- 20x20		20	20	10	-	6	45
PSP-PT- 20x30		20	30	10	-	6	45
PSP-PT- 20x40		20	40	10	-	6	45
PSP-PT- 24x7		24	7	10	-	10	45
PSP-PT- 24x15		24	15	10	84	10	45
PSP-PT- 24x20		24	20	10	-	10	45
PSP-PT- 24x30		24	30	10	-	10	45
PSP-PT- 24x40		24	40	10	-	10	45
PSP-PT- 30x15		30	15	14	-	14	45
PSP-PT- 30x20		30	20	14	-	14	45
PSP-PT- 30x30		30	30	14	-	14	45
PSP-PT- 30x40		30	40	14	-	14	45
