Gallery : View more
Brand : N-Force
Item Details
| Item code | CAD | W mm | Z | Smm | WF Kg | WFM Kg | SL Kg | SL1 Kg | SLM Kg | wt Kg | N mm | W1 mm | b mm | e mm | f mm | k mm | ka mm | l mm | t mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PCU-CS1 - 400-00-60 | 400 | 0 | 60 | 137.3 (14.0) | 205.9 (21.0) | 301.0 (30.7) | 8573 (874.2) | 9325 (950.9) | 203 | 356 | 435 | 525 | 112.5 | 300 | 200 | 142.5 | 505 | 20 |
